4000 Series Flex-Wing Rotary Cutters

Everything we love about the Apex series, taken up a notch!
The Rhino 4000 “Epic” series rotary cutters boost the horsepower requirement to 60, getting the the ability to cut brush up to 4” in diameter! The stronger gearbox is tested up to 250 horsepower, while the whole unit is protected by a safety chain!

Couple that with slip-clutch protection and hydraulic wing-lift -- and you’ve got a monster rotary cutter not to be taken lightly!

Features and Benefits

  • 60 Horsepower PTO Requirement
  • 250 Horsepower Gearbox
  • Chain Guard Safety Deflectors
  • 3 Optional Wheel Configurations

Who Should Buy

  • General Mowing
  • Pasture Maintenance
  • Shredding Crops and Stalks
  • Roadside and Right-of-Way Mowing
  • Commercial Mowing
  • Farm Use
  • Heavy-Duty Agriculture Use
  • Industrial Mowing

Download Literature

  • RhinoAg-Flex-Wing-2020-Pages-Reduced.pdf

Gallery

  • Video
  • Photos

Warranty

Industry-leading toughness. Industry-leading warranty.

Rhino products are built to take on whatever you can throw at them. But if something should break, you’ll be glad to know our warranties are just as strong. See your local Rhino dealer for complete details.

Full Machine Warranty

1

Year

Gearbox Warranty

6

Years

Gearbox Seal Warranty

2

Years

Limited Driveline Warranty

2

Years

Specifications

4105412541504155
Cutting Width10' 6"12' 6"15'
Transport Width *88''101.9"96''
Transport Height *80''73.2"80''
Overall Width *133''156.5"187''
Overall Length *183''171.2"183''
Cutting Height *2''-14''2''-14''2''-14''2''-14''
Self-Leveling Height AdjustmentHydraulic CylinderHydraulic Cylinder
Jack StandStandardStandard
HitchPullPull
Blade CarrierInfinityInfinityInfinityInfinity
Blades1/2'' x 4'' Parallel Lift1/2'' x 4'' Parallel Lift
Blade Overlap6''4"6''
PTO Horsepower Required60 HP50 HP60 HP60 HP
Gearbox Rating (based on field performance) - Divider250 HP160 HP250 HP250 HP
Gearbox Rating (based on field performance) - Center & Wing225 HP130 HP225 HP225 HP
Gearbox Oil (85W-140)Factory FilledFactory FilledFactory Filled
Output Shaft Diameter3''2"3''3''
Blade Tip Speed - Center 540 RPM16,286 FPM14,504 FPM16,286 FPM16,286 FPM
Blade Tip Speed - Center 1000 RPM16,380 FPM-16,380 FPM16,380 FPM
Blade Tip Speed - Wing 540 RPM16,422 FPM14,988 FPM16,422 FPM16,422 FPM
Blade Tip Speed - Wing 1000 RPM15,983 FPM-15,983 FPM15,983 FPM
Cutting Capacity (Diameter)4 1/2''4"4''4 1/2''
Driveline Size - MainCAT 6 CVCAT 5 CVCAT 6 CVCAT 6 CV
Driveline Size - WingCAT 5CAT 4CAT 5
Driveline ProtectionSlip ClutchSlip ClutchSlip Clutch
Deck Thickness7 GA10 GA7 GA7 GA
Side Skirt1/4'' AR400
Military Grade Steel
10 GA1/4''1/4'' AR400
Military Grade Steel
Tires & WheelsRhinoTrax, Foam Filled, LaminatedRhinoTrax, LaminatedRhinoTrax, Foam Filled, LaminatedRhinoTrax, Foam Filled, Laminated
Wing Lift HydraulicsStandardStandardStandard
Wing Flex (Degrees)90° Up/25° Down90° Up/25° Down90° Up/25° Down
Wing Flex - Operational (Degrees)45° Up/25° Down45° Up/25° Down45° Up/25° Down45° Up/25° Down
Safety Tow ChainStandardStandardStandard
LED Light KitStandardStandardStandard
Safety DeflectorsChain GuardsChain GuardsSingle or Double Chain GuardsSee Options
Tongue Weight1,870 lbs1,200 lbs1,840 lbs1,870 lbs
Weight (Approx)5,400 lbs4,000 lbs5,395 lbs5,455 lbs
Manuals

4105 Manuals

4125 Manuals

4150 Manuals

4155 Manuals

* Dependent on tire size
** Gearbox Ratings Based on Field Performance
